Place of Origin

Guangdong, China

Type

Japanese power cord with C7 plug

Wire gauge

VFF 2*0.75mm2

Material

Standard Copper, Bare Copper

Jacket

PVC

Color

Black

LABEL

VALUE

MODEL

IMQ02 to ST3

GROUP MODEL

MODELS DESCRIPTION

PVC PLUG TYPE 2P

STANDARD

ACCORDING TO JAPAN SPECIFICATION JIS C8303

VOLTAGE

125V

AMPERAGE

7A-12A-15A

CONDUCTORS

2P

JACKET MATERIAL

PVC/Rubber

TEMPERATURE RATING

60°

PLUG WEIGHT

26g

COLOR

Black is standard but any color available

ENVIRONMENTAL COMPLIANCE

ROHS REACH PAHS

CONDUCTOR

IEC 60320 C13

TESTING

Hi-Pot (Dielectric Withstanding Voltage), Polarity (pinout) and Continuity

COUNTRY OF ORIGIN

CHINA

OTHER VALUE

WIRE GAUGE(CUSTOMIZE)

Available Wire Styles

VFF 2*0.75~1.25~2.0mm²

VCTF 2*0.75~1.25~2.0mm²

VCTFK 2*0.75~1.25~2.0mm²
