•Technical data

•Current rating range   3~30A

•Input voltage rating  12/24 VDC

•Insulation Resistance >100MOHM (DC 500V)
•Dielectric Strength > 1,500VAC/min.

•Breakering Capacity 4 times rated current

·Mechanical/Environmental Data

•Operating Ambient Temperature: -10 to +60℃℃

•Storage Temperature Rating: -40°C  to +100°C.

•Termination: 250’’(6.3mm)quick connects or solder terminals

•Typical applications

Battery chargers, trucks, buses, RV’s, trolling motors, etc.
